Reflective Tape – Striped – 837 Series

Laminate of clear film over stripe enhances color and pattern durability

Meets federal specification L-S-300C, Reflectivity 1, Class 1

Available Colors:

Description

Our engineer-grade reflective tape is a high quality, durable, enclosed lens retroreflective material. This reflective tape offers exceptional value for permanent traffic signage applications. Meets applicable requirements for engineer-grade sheeting applications for Type 1 retroreflective sheeting as set forth in ASTM D 4956.

Excellent durability rating – 7 years when properly processed and applied

Item # Size Units / Case Pack
83720_ 2″ (50.8 mm) x 30 ft 24 / case Bulk
83730_ 2″ (50.8 mm) x 150 ft 6 / case Bulk
Yellow/Black 837201 837301 Yellow/Black (1) Red/White 837202 837302 Red/White (2)

Technical & Consumer Data

Physical Properties

Adhesive: Permanent pressure sensitive (Class 1)
Face Film: High gloss
Liner: White polyethylene coated paper
Tape Application: Minimum application temperature 4°C (40°F)
Cleaning: Clean tape surface with a mild soap and rinse with fresh water
Shelf Life: One year, when stored at 73°F (23°C), 50% +/- 5% relative humidity

Meets all other requirements set forth in ASTM D 4956 including shrinkage, flexibility, liner removal, adhesion, impact resistance, specular gloss and outdoor weathering.

Photometric Performance: Exceeds types III and IV values per ASTM D 4956. Minimum coefficient of retroreflectivity (RA) cd/lx/m2)

The physical and performance characteristics shown are averages obtained from tests recommended by
ASTM, government agencies or our own procedures. A particular roll may vary slightly from these
averages and it is recommended that the purchaser determine the suitability for his own purpose.
