Hi Performance Polyester Tape – Acrylic Adhesive – 695 Series

High coating of a premium, solvent based acrylic adhesive coating

Poly liner ensures ease in liner removal as well as allowing tape to be die cut

Excellent for plastic extrusions, irregular surfaces, metal profile extrusions and decorative trim

Description

Our 695 Series is a CLEAR Polyester film coated on both sides with a high performance, modified Acrylic Adhesive.

This product comes with a dimensionally stable siliconized red polypropylene release liner making it preferred for precision die-cut applications.  The adhesive system of this double-coated tape is extremely aggressive, exhibits high shear strength, and will bond well to nearly all materials; even to difficult surfaces like foams, PE and PP films.  It has excellent temperature, UV, aging, water vapor, and chemical resistance.   Also has good plasticizer resistance.

Applications

  • Used for interior or exterior bonding of dissimilar materials where high shear performance is required. Used in sign making, fixing decorative moldings, print finishing and stereo mounting.
  • Used for bonding rubber, plastic, metal and wood substrates; for permanent mounting of nameplates and decorative trim on appliances and furniture.
  • Used in die cut applications where precise size retention is critical.
Item # Size Units / Case Pack
69505 1/2″ (12 mm) x 36 yd 72 / case Bulk
69507 3/4″ (18 mm) x 36 yd 48 / case Bulk
69510 1″ (24 mm) x 36 yd 36 / case Bulk
69520 2″ (48 mm) x 36 yd 24 / case Bulk

Technical & Consumer Data

Physical Properties

Backing: Clear Polyester film
Adhesive: Modified Acrylic Adhesive
Liner: Red siliconized PP Film
Total Thickness: 6.5 mil  (exclusive of liner)
Adhesion to SST: 90 oz/inch
Shear Resistance: Excellent – Static & Dynamic
Temperature Resistance: up to 200°F long term

The physical properties listed above are typical test results obtained from a series of laboratory tests and should not be used for the purpose of writing specifications.  Before using this product, user shall determine the suitability of the product for his/her use; and user assumes all risks and liabilities in connection therewith.  All test procedures used are in accordance with ASTM and PSTC methods.

Downloads

Technical Data Sheet
